產品型號 | 破斷載荷 | 近似直徑 | 最小長度 | 最大長度 | 套 長 | 每米重量(kg/m) | |
DLP01-1.2 | DLP02-1.2 | 1200 | 9 | 1.5 | 1000 | 250 | 0.06 |
DLP01-1.5 | DLP02-1.5 | 1500 | 10 | 1.5 | 1000 | 250 | 0.08 |
DLP01-2 | DLP02-2 | 2000 | 11 | 1.5 | 1000 | 250 | 0.09 |
DLP01-3 | DLP02-3 | 3000 | 13 | 2.0 | 1000 | 300 | 0.13 |
DLP01-4 | DLP02-4 | 4000 | 14 | 2.0 | 1000 | 300 | 0.14 |
DLP01-5 | DLP02-5 | 5000 | 15 | 2.0 | 1000 | 300 | 0.15 |
DLP01-6 | DLP02-6 | 6000 | 16 | 2.0 | 1000 | 300 | 0.16 |
DLP01-8 | DLP02-8 | 8000 | 17 | 2.5 | 1000 | 350 | 0.18 |
DLP01-10 | DLP02-10 | 10000 | 19 | 2.5 | 1000 | 350 | 0.23 |
DLP01-12 | DLP02-12 | 12000 | 21 | 2.5 | 1000 | 450 | 0.26 |
DLP01-15 | DLP02-15 | 15000 | 23 | 2.5 | 1000 | 450 | 0.38 |
產品型號 | 破斷載荷 | 近似直徑 | 最小長度 | 最大長度 | 每米重量(kg/m) |
DLP03-1.2 | 1200 | 6 | 1.5 | 500 | 0.05 |
DLP03-1.5 | 1500 | 7 | 1.5 | 500 | 0.06 |
DLP03-2 | 2000 | 8 | 1.5 | 500 | 0.07 |
DLP03-3 | 3000 | 10 | 2.0 | 500 | 0.08 |
DLP03-4 | 4000 | 11 | 2.0 | 500 | 0.10 |
DLP03-5 | 5000 | 12 | 2.0 | 500 | 0.12 |
DLP03-6 | 6000 | 13 | 2.0 | 500 | 0.15 |
DLP03-8 | 8000 | 14 | 2.5 | 500 | 0.22 |
DLP03-10 | 10000 | 15 | 2.5 | 500 | 0.30 |
DLP03-12 | 12000 | 16 | 2.5 | 500 | 0.32 |
DLP03-15 | 15000 | 17 | 2.5 | 500 | 0.50 |
產品型號 |
破斷載荷 (kg) |
近似直徑 (mm) |
最小長度 (m) |
最大長度 (m) |
套長 (mm) |
每米重量 (kg/m) |
DLD01-1.2 | 1200 | 6 | 2 | 1000 | 250 | 0.028 |
DLD01-1.5 | 1500 | 7 | 2 | 1000 | 250 | 0.033 |
DLD01-2 | 2000 | 8 | 2 | 1000 | 250 | 0.048 |
DLD01-3 | 3000 | 10 | 2.5 | 1000 | 300 | 0.063 |
DLD01-4 | 4000 | 11 | 2.5 | 1000 | 300 | 0.091 |
DLD01-5 | 5000 | 12 | 2.5 | 1000 | 300 | 0.108 |
DLD01-6 | 6000 | 13 | 2.5 | 1000 | 300 | 0.122 |
DLD01-8 | 8000 | 14 | 3 | 1000 | 350 | 0.16 |
DLD01-10 | 10000 | 15 | 3 | 1000 | 350 | 0.18 |
DLD01-12 | 12000 | 16 | 3 | 1000 | 450 | 0.245 |
DLD01-15 | 15000 | 17 | 3 | 1000 | 450 | 0.346 |
DLD01-20 | 20000 | 18 | 3 | 1000 | 500 | 0.385 |
產品型號 |
破斷載荷 (kg) |
近似直徑 (mm) |
最小長度 (m) |
最大長度 (m) |
套長 (mm) |
每米重量 (kg/m) |
DLD02-1.2 | 1200 | 6 | 2 | 1000 | 250 | 0.028 |
DLD02-1.5 | 1500 | 7 | 2 | 1000 | 250 | 0.033 |
DLD02-2 | 2000 | 8 | 2 | 1000 | 250 | 0.048 |
DLD02-3 | 3000 | 10 | 2.5 | 1000 | 300 | 0.063 |
DLD02-4 | 4000 | 11 | 2.5 | 1000 | 300 | 0.091 |
DLD02-5 | 5000 | 12 | 2.5 | 1000 | 300 | 0.108 |
DLD02-6 | 6000 | 13 | 2.5 | 1000 | 300 | 0.122 |
DLD02-8 | 8000 | 14 | 3 | 1000 | 350 | 0.16 |
DLD02-10 | 10000 | 15 | 3 | 1000 | 350 | 0.18 |
DLD02-12 | 12000 | 16 | 3 | 1000 | 450 | 0.245 |
DLD02-15 | 15000 | 17 | 3 | 1000 | 450 | 0.346 |
DLD02-20 | 20000 | 18 | 3 | 1000 | 500 | 0.385 |
產品型號 |
破斷載荷 (kg) |
近似直徑 (mm) |
最小長度 (m) |
最大長度 (m) |
每米重量 (kg/m) |
DLD03-2.4 | 2400 | 6 | 2 | 500 | 0.032 |
DLD03-3 | 3000 | 7 | 2 | 500 | 0.038 |
DLD03-4 | 4000 | 8 | 2 | 500 | 0.054 |
DLD03-6 | 6000 | 10 | 2.5 | 500 | 0.082 |
DLD03-8 | 8000 | 11 | 2.5 | 500 | 0.121 |
DLD03-10 | 10000 | 12 | 2.5 | 500 | 0.128 |
DLD03-12 | 12000 | 13 | 2.5 | 500 | 0.132 |
DLD03-16 | 16000 | 14 | 3 | 500 | 0.17 |
DLD03-20 | 20000 | 15 | 3 | 500 | 0.192 |
DLD03-24 | 24000 | 16 | 3 | 500 | 0.256 |
DLD03-30 | 30000 | 17 | 3 | 500 | 0.354 |
DLD03-40 | 40000 | 18 | 3 | 500 | 0.386 |
