產(chǎn)品型號(hào) |
額定載荷 (t) |
W (mm) |
D (mm) |
P (mm) |
A (mm) |
O (mm) |
S (mm) |
自重 (kg) |
BK55 | 55 | 85 | 57 | 100 | 55 | 160 | 240 | 32.6 |
BK85 | 85 | 110 | 76 | 130 | 75 | 200 | 310 | 78.4 |
BK120 | 120 | 130 | 85 | 150 | 85 | 220 | 365 | 110.5 |
BK150 | 150 | 140 | 95 | 170 | 90 | 250 | 390 | 154.8 |
BK200 | 200 | 150 | 105 | 205 | 100 | 280 | 460 | 251.8 |
BK300 | 300 | 185 | 134 | 265 | 120 | 350 | 630 | 451.7 |
BK400 | 400 | 220 | 160 | 320 | 145 | 370 | 650 | 758.9 |
BK500 | 500 | 250 | 180 | 340 | 160 | 450 | 700 | 1092.2 |
BK600 | 600 | 275 | 200 | 370 | 170 | 490 | 760 | 1404.2 |
BK700 | 700 | 300 | 215 | 400 | 190 | 540 | 780 | 1703.8 |
BK800 | 800 | 325 | 230 | 420 | 200 | 554 | 850 | 1958.3 |
BK900 | 900 | 350 | 255 | 440 | 220 | 584 | 900 | 2450 |
BK1000 | 1000 | 380 | 270 | 460 | 240 | 614 | 900 | 2566.2 |
BK1250 | 1250 | 430 | 300 | 530 | 260 | 644 | 950 | 3500 |
BK1500 | 1500 | 460 | 320 | 560 | 280 | 680 | 950 | 4032 |
BK2000 | 2000 | 500 | 385 | 600 | 320 | 680 | 1050 | 5067 |
