產(chǎn)品型號 |
額定載荷 (t) |
W (mm) |
D (mm) |
d (mm) |
E (mm) |
S (mm) |
O (mm) |
自重 (kg) |
BX200-4 1/2 | 200 | 184 | 130 | 115 | 270 | 396 | 280 | 237 |
BX300-5 1/8 | 300 | 200 | 150 | 130 | 320 | 450 | 300 | 363 |
BX500-6 1/2 | 500 | 240 | 185 | 165 | 390 | 557.5 | 360 | 684 |
BX800-8 | 800 | 300 | 240 | 207 | 493 | 660 | 440 | 1313 |
BX1000-9 1/2 | 1000 | 390 | 270 | 240 | 556 | 783 | 560 | 2072 |
BX1250-10 1/5 | 1250 | 400 | 300 | 260 | 620 | 850 | 560 | 2511 |
